Constant Current LED Driver for Type C LED T8 Lamps | 120–277V Input | 0–10V Dimming
Keystone KTLD-4LT8-UV-12C-VDIM 4-Lamp Dimming Driver External LED Tubes. Designed for use with Keystone's Type C External Drive LED T8 tubes. This driver operates 3-4 of these 4' lamps and allows for crisp 0-10V dimming (dimmer not included).
Features
- Compatible with Keystone external drive T8 LED lamps
- Meets FCC Part 15 (Class B) consumer limits
- Short circuit overload and open load protection
- Type 1 outdoor, suitable for dry and damp locations
- UL8750 Recognized component
- Dimmable with 0–10V dimmer, dim maximum 10%
- Operating temperature: −20ºC/−4ºF to 45ºC/113ºF
- 85ºC/185ºF maximum case temperature
- Input frequency: 50/60 Hz
- THD: <20%
Downloads
Caution
Disclaimers
Extra Information
Brand:
Keystone Technologies
UPC:
890949020241
Catalog No:
KTLD-4LT8-UV-12C-VDIM
Light Source:
LED
Ballast Type:
LED Driver
Dimmable:
Yes
Max. Output Power:
48.6 Watt
Input Voltage:
120–277Vac ± 10%
Output Voltage:
36–45 Vdc
Output Current:
270mA × 4 channels
Warranty:
5 Year
