Description
100-277V Emergency LED Driver | For 0-10V Dimming Fixtures | LiFePO4 Battery
Halco 90313 BBU/EM9WU is a 9W constant-power LED emergency battery backup driver designed to convert a compatible standard LED fixture into an emergency lighting fixture. The BBU/EM9WU operates on 100-277VAC input and provides 120-200VDC emergency output for 90 minutes. It is designed for LED fixtures from 9W to 100W, with fixtures above 9W requiring 0-10V dimming compatibility, and includes a LiFePO4 battery plus a dual-function indicator light and test switch.
Product Specifications
- Brand: Halco
- Item Number: 90313
- Model Number: BBU/EM9WU
- Product Type: LED emergency battery backup driver
- Emergency Output Power: 9W constant power
- Compatible Fixture Wattage: 9W to 100W
- Input Voltage: 100-277VAC
- Frequency: 50/60Hz
- Input Current: 100mA maximum
- Input Power: 5W maximum
- Output Voltage Range: 120-200VDC, 250VDC maximum
- Emergency Duration: 90 minutes
- Battery Type: LiFePO4
- Battery Voltage: 12.8V
- Battery Capacity: 1600mAh, 20.48Wh
- Recharge Time: 24 hours
- Dimming Compatibility: Fixtures above 9W require 0-10V dimming compatibility
- LED Driver Compatibility: Works with fixtures using internal or external LED drivers
- Indicator and Test Switch: Dual-function indicator light and test switch included
- Additional Relay: Can control the standard LED driver
- Protection: Input over-current, output over-voltage, output under-current, output short-circuit, and deep-discharge protection
- Ambient Operating Temperature: 10C to 60C
- Maximum Casing Temperature: 70C
- Ingress Protection: IP20
- Design Life: 50,000 hours
- RFI/EMI Compliance: FCC
- Fixture Requirements: Use with grounded, UL Listed, damp location rated fixtures
- Dimensions: 9.45 inches L x 1.77 inches W x 1.18 inches H
- Warranty: 5 years
Benefits
- Converts a compatible standard LED fixture into an emergency LED lighting fixture.
- Provides 9W constant-power emergency output for up to 90 minutes during loss of normal power.
- Supports compatible LED fixtures from 9W to 100W for flexible emergency lighting applications.
- Works with 0-10V dimming LED fixtures, with 0-10V compatibility required for fixtures above 9W.
- LiFePO4 battery technology provides a rechargeable emergency power source with a 24-hour recharge time.
- Included indicator light and test switch simplify emergency function testing and battery status monitoring.
- Additional relay can control the fixture's standard LED driver during emergency operation.
- Built-in electrical protections help protect against over-current, over-voltage, under-current, short-circuit, and deep-discharge conditions.
- 50,000-hour design life and 5-year warranty support long-term commercial emergency lighting installations.
Applications
- Emergency conversion of compatible LED fixtures
- LED fixtures from 9W to 100W
- 0-10V dimming LED fixtures
- Fixtures with internal or external LED drivers
- Grounded UL Listed damp location rated fixtures
- Permanently installed listed emergency luminaires
- Emergency lighting in ordinary commercial locations
