Description
Interglobal Electronic Ballast for 13-watt and 20-watt T5 Fluorescent Lamps
The IG13-20EL ballast is a high-quality, electronic ballast that is designed to operate 13-watt and 20-watt T5 fluorescent lamps. It is energy-efficient and provides long lamp life. The CAT No. IG13-20EL ballast is also flicker-free and instant start, so you can enjoy bright, even illumination immediately.
Features:
- Energy-efficient
- Long lamp life
- Flicker-free
- Instant start
- UL and CSA listed
- 5-year warranty
Specifications
- Input voltage: 120VAC
- Output voltage: 160-260V
- Output current: 0.35A
- Frequency: 60Hz
- Power factor: >0.95
- THD: <10%
- Operating temperature: -40°C to 50°C
- Dimensions: 3.08" x 1.58" x 1.03"
Benefits
- Save money on energy bills
- Reduce your carbon footprint
- Improve the appearance and functionality of your space
- Enjoy long-lasting performance and peace of mind with the 5-year warranty
Downloads
Extra Information
Brand:
Interglobal
UPC:
720043487650
Catalog No:
IG13-20EL
Order Code:
IG13-20EL
Light Source:
Fluorescent
Amps:
0.56A-0.83A
Power Factor:
Normal
Start Method:
Rapid Start
Height (in.):
1.375
Length (in.):
3.50
Weight (lbs):
.75 lbs
Width (in):
1.75
Case Quantity:
50
Country of Origin:
Made in China
Maximum Temperature:
158 Deg. F
Minimum Start Temperature:
0 Deg. F
Voltage:
120V
Warranty:
1 year
Safety Rating:
UL Listed
