Description
2x2 Square LED Backlit Flat Panel with 90-Minute Emergency Battery Backup | Selectable 20/30/40W and 3500K/4000K/5000K
The Satco 65-575R1 is a 2x2 LED backlit flat panel with a built-in emergency battery backup that keeps it lit for at least 90 minutes during a power outage. Wattage and color temperature are selectable, so one fixture can match the light level and color the space needs. It is designed for 2x2 drop ceiling grids.
Features
- Built-in emergency battery backup with at least 90 minutes of operation
- Field-selectable wattage: 20/30/40W
- Field-selectable color temperature: 3500K/4000K/5000K
- 0-10V dimming
Specifications
- Product Code: 65-575R1
- Size: 2x2 ft
- Fixture Type: Backlit Flat Panel
- Wattage: 20/30/40W selectable
- Lumens: 2,200/4,600 lm
- Color Temperature: 3500K/4000K/5000K selectable
- CRI: 80+
- Voltage: 100-277V
- Dimming: 0-10V
- Beam Angle: 120°
- Rated Life: 50,000 hours
- Location Rating: Damp location
Emergency Operation
- Battery Backup: Built-in, factory installed
- Runtime: 90 minutes minimum
Installation & Compatibility
- Lays into standard 2x2 drop ceiling grids
Rebates & Certifications
- cETLus
Applications
- Offices
- Schools and classrooms
- Retail spaces
- Healthcare facilities
- Spaces that need code-required emergency lighting
Frequently Asked Questions
Does this fixture have emergency backup?
Yes. It has a built-in battery backup that runs for at least 90 minutes when power is lost.
Can I change the settings after installation?
Yes. Wattage (20/30/40W) and color temperature (3500K/4000K/5000K) are selectable on the fixture.
Is it dimmable?
Yes, with a 0-10V dimming control.
