LED Retrofit For Wall Packs, Shoeboxes And Canopies | CCT Selectable (3000K/4000K/5000K) Ballast Bypass 120-277V
Designed for efficient wall-pack and shoebox retrofits, the Topaz LWP-20WPCTS-E26 lets installers set wattage and color temperature on-site to match existing lighting needs while removing the ballast for a simpler, lower-maintenance LED conversion. With selectable 5W/10W/20W output, 3000-5000K tuning, and a rotatable E26 base with support brace, this lamp delivers targeted illumination and long life for commercial and industrial exterior fixtures.
KEY FEATURES:
- Selectable Output & CCT: Choose 5W, 10W or 20W and 3000K, 4000K or 5000K at installation to match site requirements.
- Ballast Bypass Operation: Designed for direct-wire retrofit-no ballast or external driver required for reliable LED performance.
- Thermal Protection: Internal thermal sensor reduces lamp power to 70% in extreme temperatures to protect performance.
- Adjustable Aim: 350° rotatable E26 base enables precise aiming to reduce glare and improve light placement.
- Fixture Compatibility: Suitable for enclosed fixtures up to 113°F with support brace included for secure installation.
- Wide Voltage Range: Operates on 120-277V for flexible commercial and industrial use.
APPLICATIONS:
- Ideal for wall pack retrofits where HID replacements are needed.
- Well suited for parking lot and shoebox-style luminaires.
- Appropriate for garages, canopies and sheltered exterior fixtures.
- Installation Tip: Use the 350° rotatable base and included support brace to aim light and secure the lamp in enclosed retrofit housings.
SPECIFICATIONS:
- Product Code: LWP-20WPCTS-E26
- Topaz by Halco SKU: T73511
- Wattage: Selectable 5W, 10W or 20W
- Lumens: 3000 lm
- Average Life: 50,000 hrs
- Color Temperature: Selectable 3000K, 4000K, 5000K
- CRI: 85
- Base Type: Medium (E26)
- Voltage: 120-277V
- Beam Angle: 180°
- Power Factor: 0.9
- Operating Position: Base up / Base down / Horizontal
- Suitable For Enclosed Fixtures: Yes, up to 113°F
- Housing Material: Aluminum Heatsink
- Warranty: 5 years
CERTIFICATIONS & ADDITIONAL NOTES:
- UL Listed: Yes
- RoHS: Yes
- DLC Qualified: No
- Environment Rating: Damp Locations
