60 Watt 0-10V Programmable LED Driver
Precise Dimming Control for Your 24V LED Projects
The Ace AC-A60VD24H2.5 is a high-performance, 0-10V dimmable constant current LED driver designed to provide exceptional control and power for a wide range of 24V LED lighting applications. This advanced driver boasts a wide dimming range, high efficiency, and robust safety features, making it ideal for professionals and design enthusiasts seeking a versatile solution for various low-voltage LED projects.
Key Features:
- Precise 0-10V Dimming: Offers exceptional dimming control from 15% to 100% using a standard 0-10V dimming signal, allowing for seamless adjustment of lighting ambiance.
- Powerful Performance: Delivers a maximum output power of 60W, providing ample power to drive a broad spectrum of 24V LED configurations.
- Extensive Voltage Compatibility: Accepts a universal range of input voltages (120-277 VAC) for flexible use in various electrical systems.
- Highly Efficient Performance: Maintains up to 86.6% efficiency, minimizing energy consumption and reducing electricity costs.
- Durable & Safety Certified: UL Recognized, cUL Recognized, UL 1310 Class 2 certified, and UL Outdoor Type 1 rated for safe and reliable operation in various environments.
- Silent Operation: Class A sound rating ensures quiet operation.
- Enhanced Durability: IP65 rated for protection against dust, powerful water jets, and harsh outdoor conditions.
- Long Lifespan: Offers a lifespan of 50,000 hours at 75°C case temperature, ensuring long-lasting performance.
- Updated Wiring for Safety: Features a pink wire for the negative (-) dimming connection in accordance with the 2020 NEC section 410.69 and NEMA standards.
Ace AC-A60VD24H2.5 Constant Current LED Driver Specifications
Electrical Specifications:
- Output Power: 60W
- Input Voltage: 120-277 VAC (±10%)
Input Current:
- 0.6A @ 120V
- 0.26A @ 277V
- Minimum Power Factor (PF): > 0.95 (at full load)
- Maximum Total Harmonic Distortion (THD): < 10% (at full load)
- Output Voltage: 24 VDC ± 5% (Constant)
- Output Current: 0.25 to 2.5A (Adjustable)
- Efficiency: Up to 86.6%
- Dimming Protocol: 0-10V Dimming
- Dimming Range: 15% to 100%
Physical Specifications:
- Dimensions (L x W x H): 9.50" x 1.70" x 1.14"
Lead Lengths:
- Black: 5.9"
- Blue: 5.9"
- Purple: 7.1" (Longer for remote dimming connection)
- White: 5.9"
- Red: 5.9"
- Pink: 7.1" (Negative dimming wire as per 2020 NEC and NEMA standards)
Mounting:
- Mounting Length: 8.97"
- Mounting Hole Distance: 1.2"
- Mounting Hole Diameter: 0.21"
- Weight: 1.32 lbs.
- Case Quantity: 30 pcs
Environmental:
- Operating Temperature Range: -40°C to 90°C (ambient)
- IP Rating: 65 (Dust-tight and protected against water jets from any direction)
Safety & Certifications:
Safety Certifications:
- UL Recognized
- cUL Recognized
- UL 1310 Class 2 Certified
- UL Outdoor Type 1 Rated
- Sound Rating: Class A (Quiet Operation)
- Warranty: 5 years (based on max case temp of ≤75°C); 3 years (based on max case temp of 90°C)
- Input/Output Isolation
- FCC Title 47 CFR Part 15
- Surge Protection (3 KV)
- Open/Short Circuit Protection
LED driver lifespan:
- 50,000 hours at Tcase ≤75°C
- 100,000 hours at Tcase ≤65°C
Installation:
- LED drivers shall be installed inside electrical enclosures
- Max Remote installation distance is 18 ft
- Wire Requirements: 18 AWG 600V/105C tinned strand copper lead-wires
- LED driver cases should be grounded
