Advance XI013C050V054BSM2 13W LED Driver

Advance by Signify
SKU:
PL-2721213
Philips Advance XI013C050V054BSM2
Sold by the Case of:
16 units
To help ensure safe arrival this product and to give you the lowest possible price, this item is only sold in case quantities.  Price shown is per driver. View full description
$49.70
Customer Reviews
Pack
16

Description

Replacement13W Xitanium LED Driver | 0.1-0.5A | 0-10V | 120V-277V

Advance Xitanium range of downlight LED Drivers are designed to provide OEMs with ultimate flexibility. These models are compatible with standard 0-10V dimming systems to deliver reliably smooth dimming performance down to a minimum of 1%. Enabled with SimpleSet technology, these drivers offer the needed flexibility & performance for the application with precise tuning of drive currents, selectable dimming curves and adjustable minimum dimming levels. With wide operating windows, compact size and simple current adjustability, luminaire manufacturers can easily design downlight fixtures with desired lumen levels to suit the application.

Features

  • 50,000+ hour lifetime1
  • SimpleSet Programmable
  • Large operating window
  • 1% minimum dim level
  • Compatible with Fortimo
  • Downlight modules

Benefits

  • SmartMate style housing enables easy design-in with excellent thermal performance
  • Enables Simple, Fast, Flexible applicationspecific configurations
  • Enables fixture designs with comprehensive application coverage for various loads and lumen levels
  • A single source system offer optimized for performance

Application

  • Indoor Downlight applications
  • Wall sconces and ceiling surface luminaires
  • Retail
  • Hospitality
  • Offices (corridors, conference rooms, lobby areas)
  • Floodlights

Disclaimers

*This product typically ships in 7 to 10 business days. Larger quantities may take longer than stated lead-time. All lead-times are estimates and you will be notified by email if it will be longer than 10 business days to ship. Due to the speciality nature of this product, all sales are final.

Extra Information

Brand:
Advance by Signify
UPC:
929002721213
Order Number:
XI013C050V054BSM2
Input Voltage (Vac):
120-277
Output Power (W):
13 Watt
Output Voltage (V):
10-54
Output Current (A):
0.10/0.50
Efficiency@ Max. Load and 70°C Case (%):
83 / 84
Max Case Temp. (°C):
Tc-life: 80°C / Tc-UL: 90°C
Input Current (A):
0.13 / 0.06
Max. Input Power (W):
16.4
THD @ Max Load (%):
Power Factor @ Max Load:
>0.95
Surge Protection (Ring Wave, KV):
>2.5
Envir. Protect. Rating:
UL damp & dry
Dimming:
0-10V Suitable for Class 1 or Class 2 Wiring
Dimming Range:
1% ~ 100%
Minimum Output Current (A):
0.001
Other Comments:
Dimming source current: 150μA
Pack:
16
