BSL10T3UAK55PKI2 - 10 Watt Emergency LED Battery Backup Driver | 120-277V | 15-54V Output | 90-Minute Runtime | UL924
The Bodine BSL10T3 is a compact 10W emergency LED driver designed for factory or field installation in compatible LED luminaires. It provides emergency backup operation for a minimum of 90 minutes and is built for space-limited linear LED applications where reliable code-compliant emergency lighting is required.
This emergency driver features ABConnect, which eliminates the need for a separate emergency enable connector, and STSelect, which allows the self-test function to be enabled or disabled depending on the application. It is suitable for indoor and damp locations and may be installed in sealed and gasketed fixtures, including fixtures rated for wet locations.
Product Specifications
- Brand: Bodine
- Model: BSL10T3
- Product Order Number: BSL10T3UAK55PKI2
- Product Type: Emergency LED Driver
- Emergency Output Power: 10W initial regulated output
- Initial Light Output: Up to 1500 lumens
- Emergency Runtime: 90 minutes
- Input Voltage: 120-277VAC
- Input Frequency: 50/60Hz
- Input Current: 60mA max
- Output Voltage: 15-54VDC
- Output Class: Class 2 compliant
- Battery Type: High-temperature, maintenance-free lithium ion battery
- Recharge Time: 24 hours
- Test Switch: Two-wire, bi-color illuminated test switch
- Test Switch Rating: IP65 rated
- Test Switch Cable: UL 2043 plenum rated cable assembly
- Self-Test: STSelect self-test selectable
- Connection Feature: ABConnect equipped, no enable connector required
- Temperature Rating: 0C to 55C ambient
- Maximum Case Temperature: 65C
- Fixture Compatibility: Factory or field installation
- Location Rating: Indoor and damp locations
- Dimensions: 14.1 in. L x 1.18 in. W x 1.0 in. H
- Mounting Center: 13.78 inches
- Weight: 1.05 lbs
- Warranty: 5-year full warranty, not pro-rata
Benefits
- Provides 90 minutes of emergency LED operation during power loss.
- Compact 14.1-inch case works well in space-limited linear LED fixtures.
- 10W regulated emergency output delivers predictable discharge performance.
- ABConnect simplifies installation by eliminating the emergency enable connector.
- STSelect allows self-test functionality to be enabled or disabled after installation.
- IP65 bi-color test switch provides visible charging and status indication.
- Class 2 output helps support safer low-voltage LED load connections.
- Meets CEC Title 20 efficiency standards for battery charging systems.
Applications
- Linear LED fixtures
- Commercial emergency lighting
- Indoor LED luminaires
- Damp location LED fixtures
- Sealed and gasketed fixtures
- Wet-rated fixture installations when installed inside a compatible fixture
- Factory or field-installed emergency backup lighting
Installation Notes
- Designed for factory or field installation in compatible LED luminaires.
- May be used with switched or unswitched fixtures.
- If used with a switched fixture, an unswitched hot lead must be connected to the emergency driver.
- The emergency driver must be fed from the same branch circuit as the AC driver.
- Installation is not recommended where ambient temperature may fall below 0C.
- The bi-color illuminated test switch is a Class 2 device and may be remotely mounted up to 100 ft. from the emergency driver.
- For LED and AC driver compatibility, consult manufacturer technical support.
Code Compliance and Certifications
- UL924 Listed
- Tested to CSA 22.2 No. 141
- CEC Title 20 compliant
- FCC Part 15 compliant
- Class 2 output per UL1310
- UL 2043 plenum rated test switch cable assembly
