Description
Outdoor Low Profile Small Wall Light | Select 30W/25W/18W | 120V–277V | Photocell | Warm/Cool/Daylight | 3,600 Lumens
The L-0140 is a compact semi-cutoff LED wall pack delivering up to 120 lumens per watt with selectable 30W/25W/18W output and switchable 3000K, 4000K, or 5000K color temperatures. Its die-cast aluminum housing, high-efficiency driver, IP65 rating, and integrated dusk-to-dawn photocell make it a durable solution for commercial building exteriors, low-rise facilities, and security lighting applications. Designed with excellent optical uniformity and reliable wide-range voltage operation, this fixture provides long-lasting, energy-efficient illumination.
Product Specifications
- Wattage selectable: 30W / 25W / 18W
- Lumens: 3600 lm/ 3000 lm / 2160 lm
- Up to 120 LPW efficacy
- CCT selectable: 3000K / 4000K / 5000K
- CRI 70
- Input voltage: 120–277V
- Semi-cutoff distribution optics
- Power factor: 0.95
- Driver efficiency: 90%
- 0–10V dimming
- Rated life: 50,000+ hours
- Operating temp: -40°F to 113°F
- Storage temp: -40°F to 176°F
- Outdoor rating: Wet Location / IP65
- Die-cast aluminum housing with UV-resistant powder coat
- Integrated photocell included
- Dimensions: 8.39" H × 5.75" W × 2.8" D
- Warranty: 5-year limited
Benefits
- Reliable dusk-to-dawn operation reduces energy waste
- Power & CCT selectability reduces stocking complexity
- Semi-cutoff distribution improves uniformity and reduces glare
- Rugged die-cast housing ensures long service life
- High-efficiency driver supports stable output across voltage ranges
- IP65 construction suited for harsh outdoor environments
Applications
- Commercial building exteriors
- Warehouses and loading areas
- Public walkways and corridors
- Low-rise residential buildings
- Security and perimeter lighting
- Entryways and small parking structures
Downloads
Disclaimers
*This product is built to order typically ships in 2 to 3 business days. Larger quantities may take longer than stated lead-time. All lead-times are estimates and you will be notified by email if it will take longer than 5 business days to ship.
