SFLD3-HLS-CS-U-BZ-3PR Adjustable Sektor Floodlight | CCT Selectable Outdoor LED With Lens Shift And Slipfitter Mount
Designed for fast field adjustability and reliable outdoor performance, the Sektor SFLD3 delivers selectable lumen and color settings plus lens-shift optics to precisely shape light across large exterior spaces while reducing inventory complexity and installation time.
KEY FEATURES:
- Lens-Shift Technology: Quickly change between NEMA distributions to fine-tune light patterns for signage, facades, or lot lighting.
- Selectable Output: Choose 100W, 125W, or 150W to match required lumen output (13,000–22,200 lm) and energy goals on site.
- CCT Selectable: Field-selectable 3000K/4000K/5000K for visual consistency across installations.
- Flexible Mounting: Includes slipfitter for 2 3/8" tenon and trunnion mount for versatile aiming and mounting options.
- Dimming & Controls: 0-10V dimmable with integrated NEMA 3-pin receptacle for simple sensor or control integration.
APPLICATIONS:
- Ideal for commercial, industrial, and retail outdoor lighting installations.
- Well-suited for parking lots, building accents, and perimeter/security illumination.
- Designed for distribution centers, warehouses, and signage where adjustable beam patterns are needed.
- Tip: Use slipfitter mounting and lens-shift adjustments to minimize spill light and optimize uniformity.
SPECIFICATIONS:
- Watts: Selectable 100W, 125W, 150W
- Lumens: 13,000 - 22,200
- Color Temperature: 3000K, 4000K, 5000K
- CRI: 80
- Voltage: 120-277VAC
- Beam Angle: 55°, 75°, 90° (adjustable)
- Light Distribution: Lens Shift (NEMA 5, 6 or 7)
- Dimmable: Yes (0-10V)
- Average Life: 100,000 hours
- Warranty: 5 years
- IP Rating: IP65
CERTIFICATIONS & ADDITIONAL NOTES:
- Certifications: DLC 5.1 Premium, UL Listed, RoHS, FCC
- Environment Rating: Suitable For Wet Locations
- Power Factor: 0.9
