Description
SFLD3-HLS-CS-H-BZ-3PR Lens-Shift Floodlight For Commercial Exteriors | Adjustable Output With NEMA Beam Patterns For Security
The Sektor SFLD series simplifies outdoor lighting with on-site tunability: quickly dial in beam distribution, lumen output and color temperature for the exact application without swapping fixtures. Ideal for projects that demand flexible aiming and reduced SKU complexity while delivering durable, wet-location performance.
KEY FEATURES:
- Rapid Field Tuning: Lens Shift technology lets installers change NEMA beam patterns with an easy dial for precise light placement.
- One SKU, Multiple Outputs: Selectable lumen/watt settings reduce inventory and enable fast adaptation to site requirements.
- Color Flexibility: Switch between color temperatures on site to match ambient lighting or task needs.
- Multiple Mount Options Included: Slipfitter and trunnion (yoke) mounts in the box for pole or wall installations.
- Rugged Outdoor Design: Die-cast aluminum housing with tempered glass lens and IP65 wet-location rating for reliable exterior use.
- Control Ready: Integrated NEMA 3-pin receptacle and 0-10V dimming compatibility for simple integration to controls.
APPLICATIONS:
- Distribution centers and warehouse exterior lighting.
- Commercial and retail exterior illumination and signage lighting.
- Perimeter and security lighting for industrial sites and utilities.
- Installation Tip: Set desired NEMA beam pattern, then select wattage and color temperature before final aiming for fastest commissioning.
SPECIFICATIONS:
- Manufacturer: Halco Lighting Technologies
- Wattage: Selectable 100W, 125W or 150W
- Lumens: 13,000 - 22,200
- Color Temperature: Selectable 3000K, 4000K, 5000K
- CRI: 80
- Voltage: 277-480V
- Dimmable: Yes (0-10V)
- Beam Angle: 55° / 75° / 90° (Adjustable)
- Light Distribution: Lens Shift (NEMA 5, 6 or 7)
- IP Rating: IP65
- Average Life: 100,000 hours
- Power Factor: 0.9
- Mount Included: Slipfitter (2 3/8" tenon) and Trunnion (Yoke) in box
- Housing: Die-Cast Aluminum with White Powder Coat Finish
- Lens: Clear Tempered Glass
- Input Frequency: 50/60Hz
- Warranty: 5 years
CERTIFICATIONS & ADDITIONAL NOTES:
- Certifications: DLC 5.1 Premium, UL Listed, FCC, RoHS
- Location Rating: Suitable for Wet Locations
- Listing Notes: DLC Premium qualification for energy rebate eligibility in many utility programs.
