PSC-ZKV-I-11H-BLE-SR-WT Wireless TruBlu Fixture Controller | PIR Occupancy Sensor For Highbay/Lowbay With 0-10V Dimming And Photocell
Upgrade high-bay and area lighting with a compact wireless controller that adds zoning, motion-based automation, and integrated daylighting to existing luminaires. The unit streamlines retrofit installs using a Zhaga Z-10 receptacle and Bluetooth TruBlu mesh networking to reduce wiring, cut maintenance, and deliver reliable dimming control for commercial and industrial fixtures up to 40 ft.
KEY FEATURES:
- Wireless Mesh Control: TruBlu Bluetooth Mesh enables centralized zoning and remote configuration without extra control wiring.
- 0-10V Dimming, 1-Channel: Smooth, flicker-free dimming for integrated LED drivers and fixture-level light tuning.
- Integrated Photocell: Built-in daylight sensing for automatic on/off and ambient light adjustments (cannot be used with a separate photocell).
- Zhaga Z-10 Mount: Standard Zhaga receptacle for fast, tool-free integration into compatible fixture housings.
- Rugged, Outdoor-Ready: IP65 wet-location rating and wide -40°C to 70°C operating range for harsh environments.
- Mesh Repeater Capability: Can function as a repeater to extend wireless coverage across multiple fixtures.
APPLICATIONS:
- Ideal for warehouse and distribution center high-bay luminaires.
- Well suited for industrial manufacturing floors and production areas.
- Designed for outdoor area and perimeter fixtures mounted up to 40 ft.
- Usage Tip: Configure groups and scenes via the MC Connect TruBlu web portal or iOS app to optimize energy and occupancy schedules.
SPECIFICATIONS:
- Manufacturer: Halco Lighting Technologies
- UPC: 807154254163
- Brand: Halco
- Product Code: PSC-ZKV-I-11H-BLE-SR-WT
- Technology: LED Control / Bluetooth Mesh
- Mount Options: Zhaga Z-10 Receptacle
- Input Voltage: 12-24VDC
- Dimming: 0-10V, 1-Channel
- Integrated Sensors: PIR Motion Sensor and Photocell
- Operating Temperature: -40°C to 70°C (-40°F to 158°F)
- Location Rating: Wet Location / IP65
- Sold In Multiples Of: 1
- Max Mounting Height: Up To 40 ft
CERTIFICATIONS & ADDITIONAL NOTES:
- Certifications: Bluetooth NLC Certified, UL Listed, FCC, CE
- Warranty: 5-year limited warranty
- Configuration: Configurable via MC Connect TruBlu web portal or iOS phone app
