Low-Profile Under-Cabinet LED Fixture | CCT Selectable Warm-To-Daylight Tones | Dimmable For Kitchen Task Lighting
Designed for low-profile task illumination in kitchens, workstations, and display cases, the Satco 63-521 integrates selectable color temperatures and dimmable control into a slim, energy-saving LED under-cabinet fixture to reduce maintenance and improve visual comfort.
KEY FEATURES:
- CCT Selectable: Switch between 3000K, 4000K, and 5000K to match task needs and décor.
- Energy Efficient: Integrated LED consumes 6.5W while replacing up to a 30W incandescent equivalent.
- Dimmable: Supports forward or reverse phase (Triac) dimming for smooth brightness control.
- High-Quality Light: CRI 90+ for accurate color rendering in kitchens and retail displays.
- Even Illumination: Frosted polycarbonate lens with a 105° beam angle minimizes hotspots.
APPLICATIONS:
- Ideal for under-cabinet task lighting in kitchens and food prep areas.
- Well suited for workbenches, utility rooms, and closets where low-profile lighting is needed.
- Good choice for retail displays or offices needing consistent task illumination.
- Installation Tip: Mount close to the front edge of the cabinet and orient the lens toward the workspace for uniform coverage.
SPECIFICATIONS:
- Wattage: 6.5W
- Lumens: 408L - 456L
- Color Temperature: 3000K / 4000K / 5000K (Selectable)
- CRI: 90+
- Hours Rated: 50,000
- Dimmable: Yes
- Dimming Type: Forward Phase or Reverse Phase or Phase Selectable (Triac)
- Beam Angle: 105°
- Voltage: 120v
- Amps: 0.054A
- Power Factor: >0.9
- Total Harmonic Distortion (THD): <20%
- Operating Temperature: -20°C (-4°F) to +40°C (+104°F)
- Finish: Dark Bronze
- Lens Material: Polycarbonate (PC), Frosted White
- Fixture Size: Length 11.68" x Width 3.74" x Height 1.38"
- Product Technology: Integrated LED
- Incandescent Equivalent: 30W
CERTIFICATIONS & ADDITIONAL NOTES:
- Safety Certifications: cETLus - Listed
- Location Rating: Dry (IP20)
- Energy Star: No
- California Regulations: T24 Compliant; JA8 Listed; CA Prop 65 Lead
- RoHS Compliant: Yes
- ADA Compliant: True
- Warranty: 5-Years
