Description
Commercial 10-Inch Recessed Retrofit Downlight With Dual Dimming And Integrated Emergency Battery Backup For Offices And Retail
Engineered for fast commercial retrofits, this 10-inch Satco downlight combines field-selectable outputs and color temperatures with dual-dimming and an integrated emergency driver to reduce maintenance and ensure reliable egress illumination.
KEY FEATURES:
- Field-Selectable Output & CCT: Choose between 38W/31W/26W and 2700K/3000K/3500K/4000K/5000K to match space requirements.
- Integrated Emergency: Built-in emergency driver with 90 minute EM battery runtime for code-compliant backup illumination.
- Dual Dimming: Phase-cut dimming at 120V and 0-10V dimming (120-347V) for broad control compatibility.
- High Color Quality: 90+ CRI for accurate color rendering in commercial spaces.
- Long Life & Efficient: Rated 50,000 hours with high lumen outputs and >0.9 power factor for energy savings.
APPLICATIONS:
- Ideal for office retrofit projects and open-plan work areas.
- Well suited for retail environments requiring consistent, high-CRI lighting.
- Appropriate for corridors and common areas needing emergency backup integration.
- Usage Tip: Set the appropriate CCT and wattage on-site to balance lumen output and energy use for each space.
SPECIFICATIONS:
- Wattage: 38W / 31W / 26W
- Lumens: 4200 / 3700 / 3200
- Color Temperature: 2700K / 3000K / 3500K / 4000K / 5000K
- CRI: 90+
- Rated Life: 50,000 hours
- Beam Angle: 100°
- Voltage: 120-277V
- Dimming Type: Dual Dimming — Phase Cut at 120V; 0-10V at 120-347V
- Power Factor: >0.9
- Total Harmonic Distortion: <30%
- Operating Temperature: +5°C (+41°F) to +40°C (+104°F)
- Emergency Runtime: 90 Minute EM Battery Runtime
- Finish: White
- Lens Material: Polycarbonate (PC)
- Fixture Shape: Square
- Nominal Length: 10.0 inch
- Lamp Base: Integrated
CERTIFICATIONS & ADDITIONAL NOTES:
- Safety Listing: cETLus - Listed
- Energy Star: Yes
- IC Rated: True
- Location Rating: Damp
- IP Rating: IP20
- RoHS Compliant: Yes
- FCC Compliant: True
- Warranty: 5-Years
- Compliance: California T24 2016-2025; JA8 Listed
