Description
TCP LDT8312C LED Driver | Powers 3-Lamp Type C T8 Systems | 45W Remote Ballast with 0-10V Dimming for Commercial Retrofits
The TCP LDT8312C is a remote driver engineered to power three Type C LED T8 lamps, providing reliable performance for large-scale lighting upgrades. Designed for energy-efficient retrofits, this 45-watt driver delivers consistent output with dimming capability and long-term dependability in both dry and damp locations.
KEY FEATURES:
- Multi-Lamp Power: Operates up to three 4-foot Type C LED T8 lamps simultaneously.
- Energy Efficiency: Provides 45W system power with high efficacy at 138 LPW.
- Dimmable Control: Compatible with 0-10V dimmers for adjustable lighting levels.
- Durable Design: Compact housing ensures reliable installation in retrofit projects.
- Long Life Support: Rated for -20ºC operation and backed by a 5-year limited warranty.
APPLICATIONS:
- Ideal for office, retail, and school retrofits requiring reliable LED driver solutions.
- Perfect for facilities upgrading from fluorescent systems to high-efficiency LED panels.
- Best used in 3-lamp Type C T8 applications with 0-10V dimming control systems.
SPECIFICATIONS:
- Wattage: 45W
- Lumens: 5,400
- Efficacy: 138 LPW
- Voltage: 120-277V
- Dimensions: 1.7" x 5.4" x 1.1"
- Operating Temperature: -20ºC
- Lifespan: 50,000 hours
- Dimmable: 0-10V
CERTIFICATIONS & ADDITIONAL NOTES:
- Safety Certifications: UL, ETL, DLC, RoHS Compliant
- Location Rating: Damp/Dry locations
- Warranty: 5-year limited warranty
