Description
SAL-100-T5-50-U High-Output SekTor Flood Light With Type V Optics | Daylight (5000 K) | IP65 Wet-Rated 100W Fixture
Upgrade site lighting with a high-efficacy area luminaire that delivers bright Daylight output while minimizing maintenance and energy costs thanks to industry-leading lumen-per-watt performance.
KEY FEATURES:
- High Efficacy: Delivers 14,788 lumens at 148 lm/W for exceptional energy savings versus legacy HID fixtures.
- Robust Outdoor Design: Die-cast aluminum housing with PC TIR optics and IP65 rating for reliable wet-location performance.
- Precise Distribution: Type V optics provide uniform site illumination ideal for wide-area coverage.
- Flexible Control: Standard 0-10V dimming enables simple lumen-level control and energy management.
- Long Life & Warranty: L70 >100,000 hours with a 5-year standard warranty for reduced replacement cycles.
APPLICATIONS:
- Parking Lots and Large Outdoor Lots.
- Roadway and Site Perimeter Lighting.
- Commercial Campuses and Security Lighting.
- Usage Tip: Mount with recommended slip-fit or trunnion options to optimize Type V distribution for even coverage.
SPECIFICATIONS:
- Wattage: 100W
- Lumen Output: 14,788 lm (Type V, 5000K)
- Efficacy: 148 lm/W
- Color Temperature: 5000K
- CRI: >70
- Voltage: 120-277VAC (Universal)
- Dimming: 0-10VDC Dimming
- Distribution: Type V
- Lens: PC TIR Optics
- Housing: Die-Cast Aluminum
- L70 Lifetime: >100,000 Hours
- Operating Temperature: -40°C to 45°C
- Listings: cULus, DLC Premium, FCC
- Environment: IP65 Rated
- Weight: 14.74 lbs
- Warranty: 5 Years Standard
- Bug Rating: B4 U0 G4
