LWA-2-WS-CS-U Compact 2-Foot Architectural Wrap Fixture | CCT Selectable | Wattage-Selectable With 0-10V Dimming
Ideal for quick, low-maintenance upgrades, the Halco ProLED 2-foot wrap simplifies installation with a snap-on prismatic lens and large wiring compartment while delivering field-selectable CCT and wattage to reduce energy use and match varied commercial lighting needs.
KEY FEATURES:
- Selectable Output: Field-selectable 15/20/25W choices to tailor light levels to the space.
- CCT Flexibility: Field-selectable 3500K, 4000K, 5000K for application-specific color rendering.
- High Efficacy: Greater than 130 lumens per watt for energy-efficient ambient lighting.
- Easy Installation: Snap-on prismatic polycarbonate lens, large wiring compartment, and multiple mounting options speed installs.
- Controls: 0-10V dimming standard; optional internal bi-level motion sensor available.
- Durable & Rated: Steel housing, UL Certified, suitable for damp locations, and backed by a 5-year warranty.
APPLICATIONS:
- Office ceilings and corridors.
- Stairwells and common areas.
- Retail aisles and general commercial ambient lighting.
- Tip: Use wattage and CCT selections to balance energy use and visual comfort per space.
SPECIFICATIONS:
- Product Code: LWA-2-WS-CS-U
- Wattage: 15 / 20 / 25W (Field Selectable)
- Performance (15W): 3500K - 1950 lm (130 LPW); 4000K - 2070 lm (138 LPW); 5000K - 1980 lm (132 LPW)
- Performance (20W): 3500K - 2600 lm (130 LPW); 4000K - 2760 lm (138 LPW); 5000K - 2640 lm (132 LPW)
- Performance (25W): 3500K - 3221 lm (130 LPW); 4000K - 3319 lm (138 LPW); 5000K - 3278 lm (132 LPW)
- Delivered Lumens: 1950-3319 (per specifications table)
- Efficacy: >130 LPW
- Selectable CCT: 3500K, 4000K, 5000K
- CRI: >80
- L70 Lifetime (Hrs): 50,000
- Voltage: 120-277VAC
- Power Factor: 0.9
- Dimming: 0-10V
- Housing: Steel
- Lens: Prismatic Polycarbonate
- Operating Temperature: -20°C to 40°C
- Listings: UL Certified, DLC, RoHS, FCC
- Environment: UL Listed for Dry/Damp Locations
- Warranty: 5 Years
