Description
70W HID Replacement - 2,340/2,556/2,502 lm - Wattage and CCT Selectable - Type B Ballast Bypass
The Keystone KT-LED18PSHID-E26-8CSB-D is a wattage-selectable LED corn bulb rated to replace compatible 70W HID lamps from an E26 Medium base. Compare this lamp with high watt bulbs and review wattage, lumen output, base, voltage and fixture requirements side by side.
Product Specifications
- Brand: Keystone Technologies
- Manufacturer Model: KT-LED18PSHID-E26-8CSB-D
- Actual LED Wattage: Selectable 9W/12W/18W
- HID Replacement: 70W
- Lumen Output: Selectable 2,340/2,556/2,502 lm
- Color Temperature: CCT Selectable (3000K/4000K/5000K)
- Base: E26 Medium
- Operation Type: Type B | Ballast Bypass (direct-wire line voltage)
- Voltage: 120-277V
- CRI: 80
- Dimmable: No
- Bulb Shape: Corn
- Rated Life: 50,000 hours
- Warranty: 5 Year
Benefits
- Field-selectable wattage reduces the number of replacement SKUs to stock
- Selectable color temperature lets one lamp cover multiple installations
- Retains the existing fixture housing when replacing compatible 70W HID lamps
- Type B ballast-bypass operation removes the existing ballast from the circuit
Applications
- Compatible post-top and area-light fixtures
- Compatible wall packs and security lights
- High bays and low bays with adequate lamp clearance
- Parking lot and shoebox fixtures
- Enclosed fixtures where the lamp is rated for enclosed use
