Name: Keystone KTLD-2LT5HO-UV-22C-VDIM
Brand: Keystone Technologies
SKU: KTLD-2LT5HO-UV-22C-VDIM
Price: 31.83 USD
Availability: InStock

Keystone KTLD-2LT5HO-UV-22C-VDIM

SKU:

KTLD-2LT5HO-UV-22C-VDIM

Description

Constant Current LED Driver for Type C T5HO Lamps | 120–277V Input | 0–10V Dimming

Keystone KTLD-2LT5HO-UV-22C-VDIM 2-Lamp Dimming Driver External LED T5. Constant Current LED Driver for Type C LED T5HO. Designed for specific use with Keystone's Type C External Drive LED T5 tubes. This driver operates 1-2 of these 4' lamps and allows for crisp 0-10V dimming (dimmer not included).

Features

Compatible with Keystone external drive T5HO LED lamps
Meets FCC Part 15 (Class B) consumer limits
Short circuit overload and open load protection
Type 1 outdoor, uuitable for dry and damp locations
UL8750 Recognized component
Dimmable with 0–10V Dimmer
Operating temperature: −20ºC/−4ºF to 45ºC/113ºF
85ºC/185ºF maximum case temperature
Input frequency: 50/60 Hz
THD: <20%

Downloads

Caution

Use only non-shunted lamp-holders. Do not install product in a fixture with shunted lamp-holders (found in all fixtures using instant start ballasts). If the current lamp-holders are shunted, remove them and replace them with non-shunted lamp-holders. Make new connections directly to terminals as indicated above.

Disclaimers

*This product is built to order typically ships in 2 to 3 business days. Larger quantities may take longer than stated lead-time. All lead-times are estimates and you will be notified by email if it will take longer than 5 business days to ship. Keystone has multiple warehouse's around the country to help serve you better.

Non-Returnable Item Notice:

Due to the sensitive electronic nature of LED drivers and the risk of improper installation, tampering, or programming, this item is non-returnable. Please confirm compatibility before purchasing. If your LED driver is defective upon arrival or during the warranty period, it may be eligible for a manufacturer warranty replacement. For assistance selecting the correct driver, please contact our support team.

Extra Information

Brand:

Keystone Technologies

UPC:

843654121314

Catalog No:

KTLD-2LT5HO-UV-22C-VDIM

Light Source:

LED

Ballast Type:

LED Driver

Current Type:

Fixed

Driver Type:

Constant Current

Dimming Type:

0-10V

Min Output Current:

500mA

Max Output Current:

500mA

Min Output Voltage:

36V

Max Output Voltage:

45V

Dimmable:

Yes

Min Input Voltage:

120V

Max Input Voltage:

277V

Size:

9.50x1.33x1.10 inches

Power Factor (Efficiency):

>0.9

Output Current:

500mA Ã— 2 Channels

Input Power:

25W Watt Ã— 2

Max. Current:

0.49A@120V

Max. Output Power:

48 Watt

Warranty:

5 Years
