Description
LED-FXSECSD28/40K Weatherproof Commercial Canopy Luminaire For Outdoors | Cool White (4000 K) | High Output Energy-Saving Design
Specifically engineered for durable outdoor illumination, this canopy luminaire reduces maintenance and energy use while delivering reliable, uniform light for commercial canopies and covered walkways.
KEY FEATURES:
- Weatherproof Construction: IP65 rating protects against dust and water for dependable outdoor performance.
- Energy-Saving Output: High lumen package (3076 lm) provides bright illumination while minimizing energy consumption.
- Universal Voltage: 100-277V input simplifies installation across varied sites and reduces inventory needs.
- Long Life & Warranty: 50,000 hour rated life with a 5-year limited warranty lowers lifecycle costs and maintenance.
- Integrated Controls Ready: Photo sensor option available for automated dusk-to-dawn operation and additional energy savings.
APPLICATIONS:
- Ideal for gas station canopies, fueling islands, and exterior covered areas.
- Perfect for outdoor retail entrances, loading docks, and service canopies.
- Well suited to parking structure overhangs and commercial facility eaves.
- Usage Tip: Pair with the included photo sensor for reliable dusk-to-dawn control and added energy savings.
SPECIFICATIONS:
- Wattage: 28 W
- Tested Wattage: 29.07 W
- Lumens: 3,076 lm
- Color Temperature: 4000K
- Color Rendering (CRI): 73
- Beam Angle: 102°
- Input Voltage: 100-277 V
- Voltage Frequency: 50/60 Hz
- Power Factor: 0.99
- IP Rating: IP65
- Rated Life: 50,000 hrs
- Warranty: 5 years
- Housing Color: Gray
- Width: 7.87 in
- Height: 8.85 in
- Length: 13 in
- Mounting Height: 10-15 ft
- Operating Temperature: -22°F~122°F
- Photo Sensor: Yes
- LM79: Yes
- LM80: Yes
CERTIFICATIONS & ADDITIONAL NOTES:
- Qualifications: UL/ETL, Energy Star, DLC, CEC, JA8, FCC, RoHS (as indicated)
- Version: 1.1, 04/05/2018
