Description
LED-FX8BLD18/42FFR/840/BK Heavy-Duty Outdoor Bollard For Pathway And Landscape Lighting | Cool White (4000 K) | Efficient IP65
Engineered for low-maintenance outdoor illumination, this LED bollard provides consistent, glare-controlled light for pathways and landscapes while cutting energy use and service intervals compared to legacy HID fixtures.
KEY FEATURES:
- Protected For Outdoors: IP65-rated housing ensures reliable performance in wet and exposed environments.
- Even, All-Around Lighting: Frosted lens with a 360° beam angle delivers uniform pathway and landscape illumination.
- Robust Electrical Design: Universal 120–277V operation with >0.9 power factor and 2KV surge protection for commercial installations.
- Long-Life Performance: 50,000-hour rated life and a 5-year warranty reduce replacement frequency and maintenance costs.
- Multiple Output Options: Lumen outputs listed as 1622 / 1217 / 811 to suit different site lighting needs.
- Simple Floor Mounting: Designed for secure floor installation using the included 3-bolt anchor configuration.
APPLICATIONS:
- Ideal for pedestrian pathways, sidewalks, and entryways.
- Well-suited for parks, plazas, and commercial landscape areas.
- Perfect for multi-family, hospitality, and campus exterior lighting projects.
- Tip: Mount to a firm floor surface using the 3-bolt anchor and space units for uniform coverage.
SPECIFICATIONS:
- Wattage: 18W
- Lumens: 1622 / 1217 / 811
- Efficacy: 90 LPW
- CRI: >80
- Color Temperature: 4000K
- Beam Angle: 360°
- Input Voltage: 120~277V
- Voltage Frequency: 50/60 Hz
- Input Current: 0.16 A
- Power Factor: >0.9
- Surge Protection: 2KV
- Replacement Wattage: 100W (MH) / 200W (Incandescent)
- Dimmable: No
- Warranty: 5 years
- IP Rating: IP65
- Rated Life: 50,000 hrs
- Weight: 16.35 lbs
- Height: 41 in
- Width: 8 in
- Length: 8 in
- Operating Temperature: -22°F~122°F
- Storage Temperature: -40°F~158°F
- Mounting: Floor (3 bolt anchor)
- Housing Color: Black
- Certifications: UL/ETL; LM79; LM80; IES File; FDA; NEMA
