Description
6.5-In LED Retrofit Engine For Indoor Fixtures | CCT Selectable Dimmable Module For Panels And Downlights
Upgrade existing indoor luminaires quickly with this compact LED retrofit engine that delivers tunable color control and reliable, low-maintenance performance. Designed for easy installation into compatible fixtures, the unit reduces energy use while providing uniform illumination ideal for offices, corridors, and general-purpose spaces.
KEY FEATURES:
- Easy Retrofit: Low-profile 6.5" form factor installs into many existing fixtures to modernize lighting without full fixture replacement.
- CCT Tunable: Select between multiple white tones on installation for exact ambiance and task lighting needs.
- Energy Efficient: 25W LED engine produces 2,500 lumens to lower energy consumption versus legacy lamps.
- Dimmable Performance: Works with dimmers down to 10% for flexible lighting scenes and additional energy savings.
- Long Life: Rated for 50,000 hours to minimize maintenance and replacement cycles.
APPLICATIONS:
- Ideal for retrofitting recessed cans, surface mounts, and shallow ceiling fixtures in offices and retail areas.
- Well suited for corridors, break rooms, and general commercial interior spaces seeking adjustable color tones.
- Great for hospitality and multi-use rooms where tunable white and dimming enhance comfort and functionality.
- Usage Tip: Pair with compatible 120V dimmers tested for LED loads to ensure smooth dimming from 10% to 100%.
SPECIFICATIONS:
- Wattage: 25W
- Lumens: 2,500
- Color Rendering Index (CRI): 80
- Color Temperature: CCT Selectable (27K/30K/40K/50K/65K)
- Dimmable: Yes (10-100%)
- Voltage: 120V
- Average Rated Hours: 50,000
- Material / Finish: Aluminum & Steel, White Finish
- Lens Material / Finish: Acrylic / Clear
- Size / Diameter: 6.5"
- LED Chip: 2835
- Power Factor: 0.98
- Operating Temperature: -40°F to 113°F
- Warranty: 5 Years
CERTIFICATIONS & ADDITIONAL NOTES:
- Safety Certifications: ETL Listed
- Location Rating: Suitable For Damp Locations
