TCP 20B60 Emergency Ballast

TCP
SKU:
TCP-03986
Typically ships in 2-3 business days* View full description
$80.00
$57.10
You save $22.90
Customer Reviews

Description

Operates T8 to T12 lamp and 4-pin PL CF - 700 Lumens - 120-277V

The TCP 20B60 Emergency Ballast provides an efficient solution for emergency lighting needs. This fluorescent ballast functions in conjunction with an AC ballast and can convert existing fixtures or new fixtures into emergency lighting when necessary. In the case of a power outage, the 20B60 will automatically switch to the emergency mode and rapidly provide high lumen output with one or two lamps for up to 90 minutes. When power is restored, the ballast automatically changes back to its charging mode. The 20B60 is compatible with a variety of fluorescent lamps ranging from 17W-110W T8-T12 to 18W-50W 4-pin long compact lamps and has initial light output of up to 700 lumens for one or two lamps. If used in an emergency only fixture, no AC ballast is needed.

Features

  • UL Listed (Factory or Field Installation)
  • 90 Minute Illumination
  • Max Initial Lumen Output - 700 Lumens
  • 5 Years Full Warranty (NOT pro-rata)
  • Dual Voltage Input, 120/277 VAC, 60 Hz
  • AC Input Current 280mA
  • AC Input Power Rating, 3.5 Watts
  • Battery Charging Power 3.6V - 280mA
  • 24 Hours Recharge Time w/ LED Charging Indicator Light

Downloads


Disclaimers

*This product typically ships in 2 to 3 business days. Larger quantities may take longer than stated lead-time.  All lead-times are estimates and you will be notified by email if it will take longer than 5 business days to ship.

Extra Information

Brand:
TCP
UPC:
762148039860
Catalog No:
20B60
Order No.:
03986
Light Source:
Fluorescent
Case Quantity:
1
Country of Origin:
Made in China
Dimmable:
No
Energy Star:
No
UL Listed:
Yes
Voltage:
120-277V
Warranty:
5 Year
Length (in.):
9.50
Width (in.):
2.40
Height (in.):
1.50
Price Shown:
Per Ballast
