Description
150W HID Replacement - 8,210 lm Max lm - Wattage and CCT Selectable - Type B Ballast Bypass
The Keystone KT-LED50PSHID-FC-E26-8CSB-D is a wattage-selectable ED23 LED bulb rated to replace compatible 150W HID lamps from an E26 Medium base. Compare this lamp with high watt bulbs and review wattage, lumen output, base, voltage and fixture requirements side by side.
Product Specifications
- Brand: Keystone Technologies
- Manufacturer Model: KT-LED50PSHID-FC-E26-8CSB-D
- Actual LED Wattage: Selectable 50W / 35W / 25W
- HID Replacement: 150W
- Lumen Output: 8,210 lm Max lm
- Color Temperature: CCT Selectable (3000K/4000K/5000K)
- Base: E26 Medium
- Operation Type: Type B | Ballast Bypass (direct-wire line voltage)
- Voltage: 120-277V
- CRI: 80
- Dimmable: No
- Bulb Shape: ED23 / ED23.5
- Maximum Overall Length: 7.92 in
- Diameter: 3.78 in
- Rated Life: 50,000 hours
- Certifications: UL Listed
- Warranty: 5 Year
Benefits
- Field-selectable wattage reduces the number of replacement SKUs to stock
- Selectable color temperature lets one lamp cover multiple installations
- Retains the existing fixture housing when replacing compatible 150W HID lamps
- Type B ballast-bypass operation removes the existing ballast from the circuit
Applications
- Post top and decorative acorn fixture retrofits
- Commercial pole-mounted luminaires
- Area lights and wall packs
- 150W metal halide to LED upgrade projects
- Enclosed fixtures where the lamp is rated for enclosed use
