Description
100W HID Replacement - 5,285 lm Max lm - Wattage and CCT Selectable - Type B Ballast Bypass
The Keystone KT-LED35PSHID-FC-E26-8CSB-D is a wattage-selectable ED17 LED bulb rated to replace compatible 100W HID lamps from an E26 Medium base. Find compatible high wattage LED bulbs for additional options by wattage, lumen output, base and installation method.
Product Specifications
- Brand: Keystone Technologies
- Manufacturer Model: KT-LED35PSHID-FC-E26-8CSB-D
- Actual LED Wattage: Selectable 35W/27W/20W
- HID Replacement: 100W
- Lumen Output: 5,285 lm Max lm
- Color Temperature: CCT Selectable (3000K/4000K/5000K)
- Base: E26 Medium
- Operation Type: Type B | Ballast Bypass (direct-wire line voltage)
- Voltage: 120-277V
- CRI: 80
- Dimmable: No
- Bulb Shape: ED17
- Maximum Overall Length: 5.63 in
- Diameter: 2.78 in
- Rated Life: 50,000 hours
- Certifications: UL Listed
- Warranty: 5 Year
Benefits
- Field-selectable wattage reduces the number of replacement SKUs to stock
- Selectable color temperature lets one lamp cover multiple installations
- Retains the existing fixture housing when replacing compatible 100W HID lamps
- Type B ballast-bypass operation removes the existing ballast from the circuit
Applications
- Post top and decorative acorn fixture retrofits
- Commercial pole-mounted luminaires
- Small area lights and wall packs
- 100W metal halide to LED upgrade projects
- Enclosed fixtures where the lamp is rated for enclosed use
Downloads
Disclaimers
*This product is built to order and typically ships in 2 to 3 business days. Larger quantities may require additional processing time. All lead times are estimates, and you will be notified by email if the order is expected to take longer than 5 business days to ship.
