Keystone KT-LED80PSHID-H-EX39-8CSB-D

SKU:
KT-LED80PSHID-H-EX39-8CSB-D
Typically ships in 2-3 business days* View full description
$170.49
Customer Reviews

Description

Horizontal HID LED Lamp | Power Select | Color Select | EX39 Base

The Keystone Direct Drive LED Series wall Pack/shoebox lamps with dedicated color temperatures also feature Power Select technology are an excellent choice to provide long lasting, energy efficient LED illumination for your post-top or bollard application.The Keystone KT-LED80PSHID-H-EX39-8CSB-D Mogul base LED wall Pack/shoebox lights are designed to be more efficient than Metal Halide bulbs. This LED corn bulb offers 3 wattages of 80/63/54W and Selectable Color Temperature 3000K/4000K/5000K to emit 7505 - 11600 lumens and replaces up to 320W MH Equal lamps. The integral driver eliminates the need for external driver or legacy ballast.

Features

  • Replacement for conventional metal halide lamp
  • Optimized for horizontal applications, ideal for wall pack retrofits
  • Environmentally friendly: No mercury used
  • Instant startup
  • Integral driver eliminates the need for external driver or legacy ballast; includes 4kV surge protection
  • Not for use with standard dimmers; see instructions50,000+ hour lifetime
  • Operating temperature: 30*C/-22*F - 45*C/113*F
  • Suitable for use in enclosed fixtures • inimum lamp compartment dimensions: 8” x 8” x 8.7”
  • UL listed
  • IP64 rated; integrated heat sink quickly dissipates heat and guides water intrusion out of the lamp

Downloads


Caution

Use only non-shunted lamp-holders. Do not install product in a fixture with shunted lamp-holders (found in all fixtures using instant start ballasts). If the current lamp-holders are shunted, remove them and replace them with non-shunted lamp-holders. Make new connections directly to terminals as indicated above.

Disclaimers

*This product is built to order typically ships in 2 to 3 business days. Larger quantities may take longer than stated lead-time.  All lead-times are estimates and you will be notified by email if it will take longer than 5 business days to ship. Keystone has multiple warehouse's around the country to help serve you better.


Extra Information

Brand:
Keystone Technologies
UPC:
843654138923
Catalog No:
KT-LED80PSHID-H-EX39-8CSB-D
Wattage:
Selectable 80W/63W/54W
Color Temperature:
CCT Tunable (3000K/4000K/5000K)
Base:
EX39 (Mogul)
CRI:
>80
Dimmable:
No
Life Hours:
50,000
Lumens:
Up to 10800 Lumens
Equivalent:
320 Watts
UL Listed:
Yes
Voltage:
120–277V
Warranty:
5 Year
